Description
Twin bike with luggage rack on the right side instead of pedals. Equipped with two gears on the drive train for heavy loads and steep hills.
Bike sizing:
- Riders from 1m50 up to 1m90.
- Seat moves back and forward like in a car
- Seat can be moved up and down in 5 steps
- Frame can be changed in length in 3 steps (S, M, L). This takes about an hour and tools are needed.
- The handle bar can be moved up/down and in/outFrame breaks down into 5 parts.
- This has proven to be a huge benefit in terms of maintenance, repair ability and transportation.
- Power: 250w e-assist (500W for North America)
- Max speed: 25km/h for Europe, 30km/h for North America (can be changed on the display background menu)
- Maximum rider weight: 120kg
- Frame material: 6061 T6 aluminum
- Approximated bike weight 60kg
- Can be equipped with an optional chair for a passenger.
Luggage rack:
- Rated for 50kg load
- 45cmx77cm platform
Battery:
- Samsung Lithium Ion
- 48v – 20Ah (other sizes also available)
- About a 40~60km range per battery depending on load and assist level
- Room for 2 spare batteries. This has proven to be a huge benefit in terms of bike readiness.
- Affordable and easy to replace/recycle at end of life.
- GenX™ drive by wire generator:
- gear count: 22, higher gears can be locked out.
- Pedaling Nm and Wattage limit: 70Nm – 500W
- Start-up gear can be set to preference.
- No maintenance
- Easy to replace
- Firmware can be updated.
Traction motor:
- 500W RMS(250W drive by wire, 250W Assist), 1200W peak. High efficient sine wave permanent magnet motor with active fan and aluminum housing.
- Gearbox: All hardened steel gears and differential in oil bath. 2 gears are controlled by a manual gear changer.
- 220Nm in low gear – 12km/h max speed – extreme hill climbing abilities
- 90Nm in high gear – 25km/h max speed
- Modular – easy to maintain and replace.
- Standard regenerative braking up to 550W (can be adjusted on the display background menu)
- The assist strength can be set on the display.
- Reverse mode (can be controlled by throttle if present)
Controller/lcd:
- Sine wave 500W RMS; 1200W peak. Embedded into the bike frame.
- Equipped with temperature sensor and automatic temperature rollback to protect equipment.
- Can be equipped with a throttle. The further the throttle is engaged, the more torque you get for precise control of the bike. It can legally be used in Europe as a walk assist if limited to 6km/h. This has proven to be useful for extra control of the bike inside a warehouse.
- Large LCD with USB output for charging a device
- 11 background display parameters that can be changed to customize your bikes characteristics.
- Firmware can be updated.
- Rear wheels: 3.5-10 aluminum rims, motorcycle style disc brakes. Rated for 200 kg/wheel.
- Front wheel: 20″ cast magnesium bicycle wheel with mechanical disc brakes. Equipped with ebike anti flat tire.
- Front fork: downhill style heavy duty suspension fork
- The front and rear mud guards.
lights:
- Front led light with high brightness. Embedded horn that can be controlled from the handlebars
- 4 Rear led lights with embedded brake light feature. (brightness goes up when brake is operated)
Dimensions
-
- Width: 1 m
- Length: 1.81 m
